This vertical section shows the door head interface with an exterior masonry wall and steel framing. A box stud header provides structural support above the opening, integrated with a steel plate and exterior steel frame. Sheet metal flashing is detailed with a minimum four-inch lap to provide weather resistance and drainage above the door frame.
ALIGN W1 DIM POINT EXTERIOR STEEL FRAME SHEET METAL FLASHING DIM POINT BOX STUD HEADER MIN. LAP 4" STEEL PLATE
