A wide flange column connects to a beam and a diagonal brace at a structural intersection. A gusset plate connects the brace to a continuous plate, utilizing quarter-inch fillet welds as indicated on the drawing. The beam connects to the column utilizing standard holes and connections per plan with equal spacing. A work point is established at the intersection of the centerlines of the column, beam, and brace.
BEAM PER PLAN (1/4" SLOPE) COLUMN PER ELEVATION CL BRACE BRACE PER ELEVATION WP CL BEAM CL COLUMN CONN PER S501 W/ STD HOLES 1/4 1/4 GUSSET TO CONT PL PERP CONN PER 4/S502 EQ EQ W COL 7" @ NOTE: FOR ADDITIONAL INFORMATION, SEE . / 4 S331 1/4 NTS 6 TOP BRACED FRAME CONNECTION (W COLUMN)
