A CoreBrace buckling-restrained brace connects via a bolted lug to gusset plates welded to a wide-flange steel column and wide-flange beams. The gusset and attachment are designed by CoreBrace with stiffener plates provided near side and far side as required. A concrete slab over metal deck frames into the column per plan, alongside a shear connection between the beam and column. The work point is established at the intersection of the framing centerlines.
STIFF PL NS & FS AS REQ'D BY COREBRACE,TYP SEE DETAIL XX/XX FOR MOMENT CONNECTION OF BEAM TO COLUMN STIFF PL AS REQ'D BY COREBRACE TYP WF COL PER PLAN COREBRACE BRB TYP WP WF BM PER PLAN GUSSET AND ATTACHMENT DESIGNED BY COREBRACE TYP CONCRETE OVER METAL DECK PER PLAN
