A concrete slab over a steel deck bears on a continuous steel angle connected to a steel embed plate cast into a concrete shear wall. The embed plate is secured with three-quarter-inch diameter by five-inch long headed stud anchors at specified spacing. The continuous deck bearing angle is welded to the embed plate with a three-sixteenths-inch fillet weld. A continuous reinforcing bar is placed at the deck bearing. At the contractor's option, a construction joint with a roughened surface to one-quarter-inch amplitude is provided at the wall interface.
AT CONTRACTORS OPTION PROVIDE JOINT (ROUGHEN SURFACE TO 1/4" AMPLITUDE) DECK BEARING ANGLE: L__________ x CONT W/ __"Ø x __" DBA @ __" O.C. STEEL EMBED PLATE: __"x__"x__" W/ 2-3/4"Ø x 5" LONG HSA @ __" O.C. 3/16 1-#_ CONT AT DECK BEARING CONC SHEAR WALL CONC OVER STEEL DECK DECK BEARING ANGLE: L__________ x CONT W/ __"Ø x __" DBA @ __" O.C. STEEL EMBED PLATE: __"x__"x__" W/ 2-3/4"Ø x 5" LONG HSA @ __" O.C. 3/16 CONC SHEAR WALL AT CONTRACTORS OPTION PROVIDE JOINT (ROUGHEN SURFACE TO 1/4" AMPLITUDE) CONC OVER STEEL DECK 1-#_ CONT AT DECK BEARING 1" CLR 1" CLR NOTE TO ENGINEER:
