Metal deck bears on a structural steel beam adjacent to a seismic gap specified per architectural drawings. The metal deck is welded to the support per detail requirements. A designated seismic gap separates the deck assembly from the adjacent vertical concrete or masonry element. Common details and callouts are referenced on sheet S1.23.
SEISMIC GAP PER ARCH. WELD DECK TO SUPPORT PER MTL DECK STL BM 7 S1.23 FOR DETAILS & CALLOUTS IN COMMON SEE 9 S1.23
