An HSS post is welded to a half-inch by five-inch by one-foot base plate secured to a concrete slab, deck, or curb with four half-inch diameter mechanical anchors providing two inches of embedment. Ordinary studs are fastened to both sides of the post at twelve inches on center using powder-actuated fasteners, with the first fastener positioned a maximum of six inches from the stud ends. Metal track framing abuts the post on either side per the stud wall schedule.
STUD BOTH SIDES W/ POWDER ACTUATED FASTENER (PER GENERAL NOTES) @ 12" O/C TO POST (1st FASTENER 6" MAX FROM STUD ENDS) CONDITION AT CONCRETE SLAB A A HSS POST BASE PL 1/2"x5"x1'-0" W/ (4) 1/2"Ø MECHANICAL ANCHORS PER GENERAL NOTES (2" EMBED) ORDINARY TRACK PER STUD WALL SCHEDULE ON 2-S6.71B CONCRETE SLAB / DECK / CURB A
