A hollow structural section measuring 6x4 inches connects to a concrete wall via a three-quarter-inch embedded steel plate. The structural steel tube attaches to the plate using a quarter-inch fillet weld applied on three sides typically. The embedded plate measures 1 foot tall by 10 inches wide with typical anchor placement.
HSS 6x4 (FLAT) CONC WALL PER PLAN EMBEDED PL 3/4 10" 4" 4" 1'-0" 2" 8" 2" 4" (TYP) 6" 1/4 3-SIDES (TYP) (TYP) 1"
