A steel column sits on a steel base plate bedded on non-shrink grout over a concrete pier or footing. The column assembly integrates with a concrete foundation wall and a concrete slab on grade, maintaining three inches of minimum concrete cover around the column base. Horizontal wall reinforcement continues through the concrete pier, and three ties are spaced in the top five inches of the pier. A blockout in the slab is poured solid after the column has been installed.
Ftng-Steel-Column-At-Wall STEEL COLUMN 3" MIN CONC COVER AROUND COLUMN BASE STEEL BASE PLATE ON NON-SHRINK GROUT CONCRETE SLAB ON GRADE EXTERIOR SLAB OR GRADE CONC FOOTING PLAN VIEW COVER 3" CONC FDTN WALL STEEL COLUMN CONCRETE PIER STEEL BASE PLATE ON NON-SHRINK GROUT BLOCKOUT IN SLAB POUR SOLID AFTER COLUMN HAS BEEN INSTALLED CONCRETE SLAB ON GRADE EXTERIOR SLAB OR GRADE BLOCKOUT FOUNDATION WALL AS REQUIRED FOR STEEL COLUMN PLACEMENT CONC FOOTING PLAN VIEW 3" TYP CONC FDTN WALL HORIZ WALL REINF CONT THRU PIER 3 TIES IN TOP 5" OF CONC PIER TOF SEE PLAN TOF SEE PLAN TOCP SEE PLAN B A
