Boundary reinforcing connects at the top of a foundation footing for a concrete shear wall. Vertical wall reinforcing bars extend from footing dowels, spliced together using mechanical couplers. Typical boundary reinforcing and wall reinforcing are detailed with horizontal boundary ties extending into the footing. The edge of the shear wall is positioned with a typical three-inch clearance, and vertical dowels match the vertical reinforcing size and spacing.
MECHANICAL COUPLERS - SEE DETAIL 13/S-303G "Ldh" 3" TYP EDGE OF SHEAR WALL - SEE PLAN TOP OF FOOTING DOWELS TO MATCH VERTICAL REINF TYPICAL WALL REINFORCING TYPICAL BOUNDARY REINFORCING EXTEND BOUNDARY TIES INTO FOOTING, TYP. SEE "SHEAR WALL CONSTRUCTION NOTES" NOTE 11.
