Framing configurations for typical corners and cross wall intersections in stud construction. Wall studs are sized per the structural schedule and fastened with number ten screws spaced at twelve inches on center typically. Cross wall junctions incorporate stud connections at panel joints with fasteners secured to each stud as indicated.
TYPICAL CORNER TYPICAL CROSS WALL WALL STUD REF. SCHEDULE #10 SCREWS @ 12" o.c. TYP. TYPICAL CROSS WALL AT PANEL JOINT WALL STUDS REF. SCHEDULE #10 SCREWS @ 12" o.c. EACH STUD TYP.
