A hanger connection is tied into a concrete deck, wide flange beam, and MCx channel edge beam. The assembly incorporates L3x3x3/8 angles running typically along the channel, detailed with 3/16 fillet welds. Quarter-inch stiffeners are positioned on each side of the beam web per AISC standards. Hollow structural section members align with centerline dimensions per plan, with additional hangers provided where required.
PER ARCH 9" HANGER PER PLAN CONC DECK PER PLAN MCx EDGE BEAM PER PLAN CONN PER AISC + 1" k PER 1/4" STIFFENER ON EA OF BM WEB Wx BEAM PER PLAN 3/16 TYP 3/16 3/16 TYP 2 S-703 2/ L3x3x3/8, TYP ALONG MCx HSS CL HSS CL PER PLAN ADD'L HANGER, WHERE OCCURS PER PLAN
