This structural detail shows a shear plate and gusset assembly featuring one-and-one-quarter-inch oversized holes in the shear plate provided at the contractor's option. Three-eighths-by-two-by-two-inch plates serve as typical weld washers placed over the connection. A five-sixteenth-inch fillet weld is applied on two opposing sides of the weld washers typical.
CL OF SHEAR PL AND GUSSET SHEAR PLATE w/ OVERSIZE HOLES AND WELD WASHERS SECTION B-B 9" 5/16 TWO OPPOSING SIDES OF WELD WASHERS TYP. PL 3/8x2x2 WELD WASHER TYP. 1 1/4" OVERSIZE HOLES IN SHEAR PLATE AT CONTRACTOR'S OPTION REF. NOTE 4
