A steel joist ties into a column support beneath a 3x6 Douglas Fir number two minimum member at the warehouse, secured with a five-eighth-inch diameter machine bolt. A joist brace configured per manufacturer recommendations attaches with four 10d nails. The top chord receives a steel strap such as a Simpson MST37 with forty-two 16d nails or a Simpson MST27 with thirty 16d nails, split evenly into each member. Two rows of continuous edge nailing are provided at strapped members, utilizing four lines where nailing is staggered and six lines where three lines are required. An extra layer of ninety-pound felt or equal per roofer recommendation covers the exposed steel strap.
PROVIDE (2) ROWS AT CONT EDGE SPACING AT STRAPPED MEMBERS (4 LINES WHERE NAILING IS STGRD, 6 LINES WHERE 3 LINES OF NAILING IS REQD) EXTRA LAYER OF 90# FELT OVER EXPOSED STEEL STRAP OR EQUAL PER ROOFER'S RECOMMENDATION (4) 10d NAILS JOIST BRACE WHERE OCCURS PER MFR'S RECOMMENDATION STEEL JOIST 5/8" DIA MB 3x6 DF #2 MIN AT WAREHOUSE UNDER NAIL STRAP MARK STRAP & NAILS * SIMPSON MST37 W/ (42) 16d SIMPSON MST27 W/ (30) 16d 4A 4B * USE HALF OF REQUIRED NAILS IN EACH MEMBER 21 - 1 1
