Cold-formed steel framing details show single stud, back-to-back two-stud jamb, and back-to-back three-stud jamb configurations. Two rows of number eight screws at twenty-four inches on center fasten the built-up members together, with number eight screws at twenty-four inches on center applied to each flange. A continuous track matches the stud thickness at the head or base. Alternatively, a weld option is permitted at the contractor's discretion.
SINGLE STUD 1/8 1-24 AT CONTRACTOR'S OPTION IN LIEU OF SCREWS (2) ROWS #8 SCREWS AT 24" OC CONT TRACK TO MATCH STUD THICKNESS 1/8 1-24 AT CONTRACTOR'S OPTION IN LIEU OF SCREWS #8 SCREWS AT 24" OC EA FLANGE BACK-TO-BACK JAMB (2 STUDS) BACK-TO-BACK JAMB (3 STUDS) TYPICAL JAMB STUD CONFIGURATIONS
