The wide flange beam frames into the web or flange of a wide flange column using a minimum three-eighths inch thick single plate shear tab. The connection is secured with ASTM A325 bolts as required, with a minimum of two bolts. The shear tab is welded to the column flange, and the beam web is bolted through the plate.
BEAM AS PER PLAN WIDE FLANGE COLUMN AS PER PLAN WIDE FLANGE COLUMN AS PER PLAN MIN. 3/8" THK. SHEAR TAB C/W A325 BOLTS AS REQUIRED, (MIN. 2) BEAM AS PER PLAN L C A L C TYP-S-226 TYPICAL BEAM TO WIDE FLANGE COLUMN - SHEAR TAB - WEB
