A structural end connection for a steel core assembly with a casing connects a gusset plate to the steel core plate extension, leaving a one-inch minimum clearance and a specified gap left unwelded on the gusset side only. Transverse stiffeners and casing caps are welded at each end of the casing. The plan and elevation views provide dimensional parameters for the gusset length, edge distances, and plate thicknesses.
W t D ws GUSSET PL CASING EDGE OF GUSSET PL t s W so L e W s - 1 4 L L c L st L g STEEL CORE PL EXTENSION 1" NO SHOP WELD GUSSET SIDE ONLY H C CASING STEEL CORE TRANSVERSE STIFFENER CASING CAP, EACH END t sc W s STEEL CORE PL EXTENSION e e 45°, TYP L st c L L W s - 1 4 L e L g 1" MIN 14 " TYP 8 TYPICAL END CONNECTION DETAIL SCALE: NTS PLAN VIEW
