The steel beam frames into the column web using a bolted shear tab welded to the column face, paired with top and bottom continuity plates matching the beam flanges. The shear tab thickness equals the beam web thickness plus one quarter of an inch. Continuity plates are welded to the column flanges with specified weld sizes and are omitted on one side if the dimension is less than three inches. Edge distances and bolt spacings follow AISC specifications with bolt sizes and counts sized per plan.
BEAM TO COLUMN WEB CONNECTION A (DIFFERENT BEAM DEPTH) FOR EDGE DISTANCE AND BOLT SPACING SEE AISC SPECIF, TYP SHOWN ON PLAN THUS: No & SIZE OF BOLTS (SEE NOTE 3) 2ND ROW OF BOLTS AS REQUIRED, SEE PLAN TO STEEL CONTINUITY PLATE T&B (SEE DETAIL "E") SHEAR TAB THICKNESS = BEAM WEB THICKNESS + 1/4" IF LESS THAN 3" OMIT CONT PLATE THIS SIDE * SEE SCHED TF2 TF1 3" MIN TYP 2" TF1 TF2 TF1 TF2 CP T&B FLANGES, TYP UNO M *
