An HSS wind girt connects to a steel stud framing line using a supplier-provided stiff clip connection and a continuous one-quarter-inch bent plate. A one-inch plus-or-minus gap is maintained to accommodate vertical deflection and horizontal drift. The bent plate is welded with one-quarter-inch fillet welds spaced at twelve inches. The assembly accommodates movement between the structural framing and the exterior wall system.
1/4 1/4 3-12 3-12 T.O. FIN FLR HSS WIND GIRT DRIFT DRACK CONN BY SUPPLIER TO ACCOMODATE VERT DEFLECTION AND HORIZ DRIFT STIFF CLIP CONN BY SUPPLIER STL STUDS BY SUPPLIER 1" ± GAP 4" BENT PL 1/4"xCONT GIRT SEE ARCH
