An 800S162-33 cold-formed steel stud framing member spaced at sixteen inches on center bears onto a hollow structural section girt, which is sized per elevation. The girt rests on a three-eighths by ten by eight inch steel embed plate secured to the masonry wall with two three-quarter inch diameter by six inch head stud anchors. A three-sixteenth inch typical field weld secures the connection with a field-weld symbol indicating typical execution.
3/16 TYP. 800S162-33 @ 16"o.c. HSS GIRT - SEE ELEVATION EMBED PLATE 3/8" x 10" x 8" W/ (2) 3/4" DIA. x 6" HSA'S MASONRY WALL - SEE PLAN & SCHEDULE FOR SIZE & REINFORCING 1/4
