A structural steel buckling-restrained braced frame connection details the protected zones along the braces, beams, and columns. Gusset plates connect the buckling-restrained braces to the framing members while maintaining designated protected zones outside the casing ends. The casing is noted as not part of the gusset plate assembly. Fire protection of the buckling-restrained brace coordinates with architectural drawings.
END OF CASING END OF CASING NOTES: 1. INDICATES PROTECTED ZONE. 2. SEE BRB SHEET NOTES FOR PROTECTED ZONE REQUIREMENTS AND LIMITATIONS 3. COORDINATE FIRE PROTECTION OF BRB WITH ARCH DWGS. PROTECTED ZONE CASING NOT PART OF GUSSET PLATE TYPICAL END OF CASING END OF CASING NOTES: 1. INDICATES PROTECTED ZONE. 2. SEE BRB SHEET NOTES FOR PROTECTED ZONE REQUIREMENTS AND LIMITATIONS 3. COORDINATE FIRE PROTECTION OF BRB WITH ARCH DWGS. PROTECTED ZONE CASING NOT PART OF GUSSET PLATE TYPICAL
