A steel column connects to a steel embed plate through a steel base plate and side plates. Steel plate washers are installed at connection points with dimensions sized per the BRB supplier requirements.
STEEL COLUMN STEEL BASE PLATE A A A STEEL EMBED PLATE SIDE PLATE STEEL PLATE WASHER A A 1/2" SUPPLIER PER BRB B STEEL PLATE WASHER TYPE 2 C
