Horizontal reinforcing bars are positioned around concrete masonry unit wall openings at the wall centerline in the upper detail and in each face in the lower detail, maintaining a two-inch clear cover. Minimum grouted cells are provided per schedule adjacent to the edge of the opening. Additional vertical or horizontal reinforcement is referenced per sheet S5.00.
CLR 2" CLR 2" MIN GROUTED CELLS PER TABLE TYP HORIZ REINF TYP HORIZ REINF EDGE OF OPENING EDGE OF OPENING MIN GROUTED CELLS PER TABLE REINF PER 9/S5.00 REINF EACH A REINF @ CENTERLINE
