Steel joists bear on a steel girder supporting a metal roof deck above. Two one-half-inch diameter A325 erection bolts are required at all joists spanning forty feet or more. A girder bottom chord brace is provided by the joist or girder supplier, located typically at the joist nearest the mid-span of the girder and as otherwise determined by the supplier.
GIRDER BOTT CHORD BRACE BY JST / GIRDER SUPPLIER, TYP AT JST NEAREST MID-SPAN OF GIRDER AND AS OTHERWISE DETERMINED BY JST SUPPLIER. STL GIRDER MTL ROOF DECK STL JST (2) 1/2"Ø A325 ERECTION BOLTS AT ALL JSTS SPANNING 40'-0" OR MORE 3/16 TYP 1/8 3"
