A hollow structural section beam attaches to a hollow structural section column with full penetration welds and a shop weld at contractor's option in this canopy framing connection. A 3/8" x 3" plate matching the hollow structural section beam depth minus 1" is placed on each side of the beam. A canopy rod and attachment secures to the assembly with a 1/8" clearance at the back face of the bent plate. A metal deck bears above with welding per sheet reference, while a gutter is provided per architectural drawings. All steel exposed to weather receives paint per architectural specifications.
4 1 / 8" 1/8" B.O.D. AT BACK FACE OF BENT & 1/4 1/4 METAL DECK - FOR WELDING SEE . & 3/8"x3"x HSS BM DEPTH -1" EA. SIDE OF HSS BM FOR CANOPY ROD & ATTACHMENT - SEE . 1 S5.31 4 S5.04 FACE OF FINISH 4" CLR. TO HSS BM FULL P.J.P. GUTTER PER ARCH. HSS COL. 1/4 1/4 SHOP WELD AT CONTR. OPTION 5 S5.04 NOTE: PAINT ALL STEEL EXPOSED TO WEATHER - SEE ARCH. 4 5
