Metal stud tracks anchor directly to concrete slabs using screw anchors and shot anchors depending on the slab condition. Shot pins are explicitly excluded from curbs and depressed slabs. The concrete curb condition accommodates vertical adjustments with sizing referenced from structural plans, while the depressed slab utilizes standard slab and curb details.
METAL STUDS CURB SEE PLAN DEPRESSED SLAB WHERE OCCURS TRACK SLAB AND CURB PER TRACK AND SCREW ANCHORS PER DET. (SHOT PINS SHALL NOT BE USED AT CURBS) OR DEPRESSED SLAB SHOT ANCHORS PER B A 9 S0.1 4B 2 S0.6 2C S0.6
