A concrete pipe trench is formed within a slab on grade with a maximum depth of one foot six inches and a typical bottom width of one foot. Slab reinforcement matches the primary slab on grade reinforcing and continues through the trench profile with hooked ends at the trench edges. Reinforcement is lapped with a typical Class 'A' lap splice outside the trench zone. Slab thickness 't' and reinforcing sizes are sized per structural plans.
TYP 1 1 SAD FOR PIPE TRENCH DETAILS SLAB REINF SEE PLANS HOOK SLAB REINF AT TRENCH, TYP SLAB ON GRADE REINF TO MATCH SLAB REINF "t" SEE PLANS SLAB THICKNESS TYP CLASS 'A' LAP SPLICE 1'-0" "t" 1'-6" MAX
