An HSS10x6 canopy framing member connects to an HSS column using a three-eighths-inch thick end plate and intermediate connection plates. The assembly sits atop a wide-flange steel column sized per the structural column schedule. Fastener and plate layouts are detailed with specific vertical and horizontal edge distances.
3/4" 3" 1 1/2" 1/2" 1 1/2" 3" 1 1/2" 2" HSS - SEE PLAN PL 3/8x3 1/2x0'-6" HSS10x6 - SEE PLAN W/ 3/8" END PL T/STEEL SEE PLAN CONNECTION SEE 16/S-151 WF COLUMN SEE STL COL SCHED PL - SEE 1/S-152
