Framing above the slip track is sized per plan, with a six-inch-long piece of 600S162-54 cold-formed steel framing attached to the track. Two number 10 fasteners are installed on each side from the track to the six-inch stud piece, positioned outside of the slots. The connection is left disconnected from the vertical stud to allow vertical movement. A type 2 or 3 jamb stud is specified per plan.
FRAMING ABOVE SLIP TRACK SEE PLAN PIECE OF 600S162-54x6" LONG. DO NOT CONNECT TO 6" STUD (2) #10 EA FL FROM TRACK TO 6" STUD PIECE TYP NOT IN SLOTS TYPE 2 OR 3 JAMB STUD - SEE PLAN
