Vertical reinforcement extends per the shear wall elevation to within three inches of the top of the existing shear wall. Existing horizontal and vertical reinforcement remains in place. The existing concrete shear wall connects at the top of the wall according to the shear wall elevation.
11 VERT REINF PER SW EL, EXTEND TO WITHIN 3" OF TOP OF (E) SW (E) HORIZ AND VERT REINF TO REMAIN, SEE TOP OF (E) WALL, SEE SW EL (E) CONC SW (E) HORIZ AND VERT REINF TO REMAIN, SEE
