This enlarged plan details an exterior steel stair run featuring six equal treads at eleven inches spanning a total of five feet six inches with a four-foot-six-inch clear width. The assembly incorporates galvanized steel bar grate stair treads and a landing, flanked by one-and-a-half-inch diameter galvanized steel pipe handrails and guardrails. Typical protective bollards are positioned at the base of the stair run with standard one-foot offsets.
9 2 A7.0 3 1/2" 5'-0" 6 EQUAL THREADS @ 11" = 5'-6" 1'-0" 11" TYP 1'-0" TYP 1'-0" 1 1/2" 4'-6" CLEAR BOLLARD, TYP. GALVANIZED STEEL BAR GRATE LANDING, TYP. 1 1/2" DIA. GALVANIZED STEEL PIPE GUARDRAIL 1 1/2" DIA. GALVANIZED STEEL PIPE HANDRAIL GALVANIZED STEEL BAR GRATE STAIR THREADS, TYP.
