A concrete stem wall connects to a continuous footing with extended reinforcement tied into the frame footing. A thickened slab edge abuts a concrete masonry unit wall and cold-formed metal framing, maintaining a three-inch minimum joint. Vertical and horizontal reinforcing bars are detailed throughout the foundation and wall interface.
T/FTG SEE PLAN SEE ELEVATIOS FOR CF FRAMING THICKENED SLAB EDGE LTE LTE EXTEND STEM WALL & FOOTING REINF LTE INTO FRAME FOOTING 2 S3.03 3" JOINT MIN, SEE ARCH CMU WALL, SEE PLAN & S4 SERIES FOR DETAILS
