A structural column top features a routed vertical channel designed to house a concealed connector plate and associated screws referencing sheet S7.05. The assembly includes a variable vertical offset dimension referencing sheet S7.04 and a specified side cover dimension per schedule. The column is routed specifically at the top where the connector occurs per the framing plans.
TOP OF COLUMN WHERE OCCURS REF. PLAN ROUT COLUMN FOR CONN. CONNECTOR PL AND SCREWS REF. 1/S7.05 REF. S7.04 VARIES REF. SCHED. SIDE COVER
