A structural steel wide-flange beam intersects a cold-formed steel stud wall, with a ninety-seven mil track secured to the beam flange using a number twelve tek screw on each side at each stud. Minimum three continuous cold-formed steel king studs run the full height of the wall adjacent to the steel beam. Bundled bearing studs below connect to the jamb studs using a Simpson FCB clip to the top flange of the wide-flange beam. Steel studs above continue from the bottom track, which connects to the beam per standard structural details.
STEEL STUD WALL PER PLAN PROVIDE MIN (3) CONT CFS KING STUDS ADJACENT TO STL BEAM, FULL HEIGHT OF WALL. BUNDLE PER OPNG PER ARCH BEAM TO TOP TRACK 97 MIL TRACK W/ (1) #12 TEK SCREW EA SIDE AT EA STUD 1/8 1-12 1/8 1-12 JAMB STUDS TO BUNDLED BRG STUDS BUNDLED BRG STUDS BELOW PER PLAN & SIMPSON FCB CLIP FROM JAMB STUDS TO TOP FLANGE OF WF BEAM T/STL PER PLAN BOT TRACK PER PLAN, CONN TO BEAM PER 4/S6.1 STL STUDS ABOVE PER PLAN BEAM PER PLAN 2/S5.7 2/S5.7
