An 8-inch concrete masonry unit non-load-bearing wall is fully supported at its base with vertical reinforcement sized per the masonry reinforcement schedule. The end of the wall features a gap filled with firestop or waterproofing material as indicated on the architectural drawings. Horizontal reinforcement hooks match the size and spacing of the horizontal reinforcing bars.
1/2" CMU WALL, FULLY SUPPORTED AT BASE END OF WALL GAP, FILL W/ FIRESTOP OR WATER PROOFING MATERIAL PER THE ARCH DWGS VERT PER "CMU NON-LOAD BRG WALL REINF SCHED" 8" MASONRY WALL 29" Lcmu HOOKS TO MATCH SIZE & SPCG OF HORIZ REINF
