A steel column connects to a three-quarter-inch thick steel base plate secured by two three-quarter-inch diameter expansion anchors. The base plate bears on a concrete slab over a steel deck. A steel beam runs below the deck with beam web stiffener plates on each side. A three-sixteenth-inch fillet weld typically connects the column to the base plate.
STEEL BEAM CONCRETE OVER STEEL DECK STEEL COLUMN 3/4" THICK STEEL BASE PLATE W/2-3/4"Ø EXPANSION ANCHORS BEAM WEB STIFFENER PLATE EACH SIDE STAIR-19 3/16 TYP BASE PLATE (2-BOLT) EQ EQ 1 1/2" 1 1/2" 1/2"
