A plate is welded to the web and flanges of a wide-flange column with specific dimensional clearances relative to the column K-distance. Complete joint penetration welds connect the plate to the column flanges, and fillet welds sized at three-quarters of the plate thickness connect the plate to the column web. The assembly establishes precise tolerances for the plate location relative to the column centerlines and fillet dimensions.
PL tp TYP. A SECTION A-A PLAN VIEW A CL OF COLUMN 0.75tp 0.75tp COLUMN WEB C.J.P. COLUMN FLANGES K1 K MAX. 1/2" MIN. 1 1/2" WF COLUMN REF. ELEVATIONS
