Cold-formed metal studs frame on each side of a structural steel beam by others, featuring a top track sized per schedule. A three-quarter-inch deflection gap is provided below the structural slab, with a three-quarter-inch clearance maintained around the steel beam. Sheathing is cut out for clarity, and sealant is applied per the architectural requirements if required.
METAL STUD @ EA SIDE OF BM TYP PER SCHED STL BM BY OTHERS (SIM @ JOIST) TOP TRACK TYP PER SCHED TYP AROUND BM SHTG 3/4" CLR GAP 3/4" DEFL STRUCTURE BY OTHERS SEALENT PER ARCH IF REQ'D SHTG CUT OUT FOR CLARITY
