This reference detail directs the builder to check specific conditions for concrete spalls at existing guardrails where related structural details apply.
DN 3 SEE DETAIL 6/S-401 FOR CONDITIONS FOR CONCRETE SPALLS AT EXISTING GUARDRAILS WHERE DETAILS 7 & 8/S-401 ARE APPLICABLE
