An ASCE crane rail sits atop the top flange of a wide-flange structural steel crane runway beam. Rail clamps spaced at two feet on center maximum secure the rail to the beam flange using bolted connections. The runway beam size is determined per structural plans based on load requirements.
Wx CRANE RUNWAY BEAM (SEE PLANS) RAIL CLAMP PER MFR @ 2'-0" OC MAX (TYP) ASCE CRANE RAIL, PER BRIDGE CRANE MFR
