Steel window frame profiles feature a window sill at floor condition and a single rabbet profile. Dimensions show a 4 inch overall height with equal spacing and a throat opening plus 1 inch width for the sill detail. The single rabbet profile includes a 2 inch offset with a specified throat opening dimension and 1/2 inch returns. A removable stop is positioned as required on the sill detail profile.
4" 5/8" 1 1/4" 1 1/4" 1 15/16" 5/8" 2" 1/2" 1/2" THROAT OPENING SINGLE RABBET W14 WINDOW (SILL AT FLOOR) W13 REMOVABLE STOP AS REQD EQ EQ THROAT OPENING + 1"
