A structural gusset plate passes through a slotted hollow structural section or pipe column member. The slot termination features a radiused cutout defined as half the gusset plate thickness. Erection clearance is maintained around the plate with a one-sixteenth-inch gap on each side. Additional reinforcement is included as required by structural design calculations.
REINF. AS REQUIRED GUSSET $ 1/16" AS NEEDED FOR ERECTION CLR. RADIUS = gusset t 2 2 1 / 8" 3/4 " 1 /4" 1 /4" 1 /2" gusset t HSS/PIPE TYPICAL SLOT IN HSS/PIPE
