A three-quarter-inch joint between adjacent concrete tilt-up panels equipped with embed plates and deck bearing connections. A note specifies field installation criteria, requiring a new hole to be drilled in the angle at least six inches away if the distance from the tilt edge to the post-installed anchor is less than four inches.
3/4" PANEL JOINT CONC TILT-UP PANEL DECK BRG EMBED PL PER NOTE 1, IF 'X' (DISTANCE OF TILT EDGE TO POST INSTALLED ANCHOR) IS LESS THAN 4", DRILL A NEW HOLE IN ANGLE AT LEAST 6" AWAY / (1 S702) "X"
