A C 150x16 channel connects to an L52x76x6.4 angle supporting a plate element. Fasteners are spaced at fifty millimeters minimum on a one-hundred-fiftieth spacing. Additional weld symbols and dimensional indicators establish the alignment and edge clearances for the assembly.
6 100-200 50 VARIES PT_CS 6x76 / 50 MIN @ 150 6 100-200 L52x76x6.4 LLH C 150x16 SECTION A2-A2
