Cold-formed steel framing assembly at a window jamb utilizes double 600S162-43 studs spaced at sixteen inches on center typically alongside triple 600T150-43 tracks. The assembly incorporates ten gauge by four inch by zero foot six inch clip angles at the top and bottom, secured with three number 10-16 self-drilling screws to both the jamb and the track. Powder-actuated fasteners are specified at thirty-two inches on center to connect the box header to the hollow structural section column, supplemented by number 10-16 Elco Dril-Flex screws typical throughout the connection.
SECTION A-A SECTION AT JAMB (3) 600T150-43 DOUBLE JAMB STUD (.0451) 2-12 (.0451) 2-12 10 GAx4x0'-6" CLIP TOP AND BOTT. w/ (3) #10-16 SCREWS TO JAMB AND TRACK 600T150-43 w/ (2) PAF's @32" OC (2) 600S162-43 TYP. WINDOW REF. ARCH. #10-16 ELCO DRIL-FLEX TYP. (3) 600T150-43 TYP. A A 600S162-43 @16" OC TYP. NOTE: USE PAF's TO CONN. BOX HEADER TO HSS COL. 1" = 1'-0" 11 NOTE: REF. 1/S801 FOR PAF's, SCREW AND CONN. INFO. SECTION A-A SECTION AT JAMB (3) 600T150-43 DOUBLE JAMB STUD (.0451) 2-12 (.0451) 2-12 10 GAx4x0'-6" CLIP TOP AND BOTT. w/ (3) #10-16 SCREWS TO JAMB AND TRACK 600T150-43 w/ (2) PAF's @32" OC (2) 600S162-43 TYP. WINDOW REF. ARCH. #10-16 ELCO DRIL-FLEX TYP. (3) 600T150-43 TYP. A A 600S162-43 @16" OC TYP. NOTE: USE PAF's TO CONN. BOX HEADER TO HSS COL. 1" = 1'-0" 11 NOTE: REF. 1/S801 FOR PAF's, SCREW AND CONN. INFO.
