S-DJ53B — Steel Plate to HSS Railing Connection

Structural · S-DJ53B

Steel Plate to HSS Railing Connection

Materials

Elements

Beams Railings / Guards Connections / Plates

Connections

About this detail

A one-half inch by two-inch steel plate hanger connects to a hollow structural section member using typical fillet welds on both sides. A one-half inch by three-inch by six-inch steel plate is welded with one-quarter inch welds on three sides to support the assembly beneath framing. The railing is provided by others.

1/4 1/2"x3"x6" STEEL PLATE 1/2"x2" STEEL PLATE HANGER 1/4 3 SIDES 1/4 1/4 PL TO HSS, TYP PL TO HSS RAILING BY OTHERS

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
