Structural · S-DHYST

Roof Diaphragm at Architectural Cornice

Materials

Timber / Wood

Elements

Roofs

About this detail

Wood roof diaphragm framing abuts the architectural cornice. The existing sheathing aligns with the top of the existing sheathing elevation.

ROOF DIAPHRAGM ARCHITECTURAL CORNICE T.O. (E) SHEATHING B.N.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
