This diagram defines the load distribution for a PWT parallel chord truss. Snow load case one is applied as a uniform load across the top chord. A seismic load of two hundred ten pounds per linear foot is applied laterally. The dead load is represented as a uniform load acting on the truss profile. The PWT-8 truss reaction is specified at two feet on center, with support locations indicated at the truss ends.
