Steel beams frame into opposite sides of a structural column with top flange elevations matched or offset per dimensions TF1 and TF2. A shear tab welded to the column web connects to each beam web with multiple rows of bolts sized per plan and schedule. Continuity plates are installed inside the column flanges aligned with the beam top and bottom flanges. Field welds and bolt counts are specified by notes referencing the structural schedule and plan layouts.
TOP OF STEEL SHOWN ON PLAN THUS: CONTINUITY PLATES SEE TYP DETAIL, USE LARGER OF TF1 OR TF2 TYP M SEE SCHED +1/16 TF1 TF2 NUMBER AND SIZE OF BOLTS IN 1ST ROW SEE NOTE 2 NUMBER OF ADDITIONAL BOLTS IN 2ND ROW SEE PLAN
