A continuous hollow structural section tube framing member connects to a ledger at a precast concrete wall panel joint with embed plates on each side. The structural tube is coped around the ledger and reinforced with 3/8-inch by 4-inch by 0-foot-6-inch stiffener plates on each side of the tube. Embed plate "A" is secured with 3/4-inch diameter welded studs in groups of four and anchored into the concrete with two #5 by 2-foot-8-inch long dowels. The ledger splice is detailed per sheet SD.4 with specific bolting and full penetration weld requirements.
BAR JOIST TO LEDGER AT CORNER PANEL JOINT TYP. 13 SD.1 ELEVATION 5 TUBE TO LEDGER AT CORNER PANEL JOINT TYP. 13 SD.1 PLAN VI EW
