A wide flange beam frames into an intermediate hollow structural section beam with a coped top flange as shown. A three-eighths-inch thick bearing plate matching the flange width sits between the members. Wide flange beam stiffeners are welded to each side of the hollow structural section beam using a field weld. Support angles and concrete slab thickness and metal deck size and gauge are sized per plan and referenced on sheet 5/S221.
CONCRETE SLAB OVER METAL DECK - SEE NOTES FOR SLAB THICKNESS & DECK SIZE & GAUGE SEE 5/S221 FOR INFORMATION HSS BEAM - SEE PLAN W BEAM STIFFENERS ON EA. SIDE W BEAM - SEE PLAN COPE OVER HSS BEAM AS SHOWN SUPPORT ANGLES - SEE 4/S221 FOR INFORMATION BEARING PL 3/8" x REQ'D x FLANGE WIDTH BEAM STIFFENER TO HSS
